Product Description

1. Product Introduction of 3PHASE ONLINE UPS 100KVA PF1.0


The HX33 series (3PHASE ONLINE UPS 100KVA PF1.0) provide a balanced, efficient, industrial power to application.

3PHASE ONLINE UPS 100KVA PF1.0 is a high-performance digital UPS using the DSP control technology.

3PHASE ONLINE UPS 100KVA PF1.0 is connected between the mains and critical loads to supply high-quality power to the loads.


The 3-Phase 380/400/415V 10kVA 10kW Online Double Conversion UPS with IGBT technology provides battery backup and AC power protection against power disturbances. It’s recommended for critical IT or corporate infrastructure, telecom, LAN/WAN, security and emergency, financial and light industrial applications.

Get more details of 3PHASE ONLINE UPS 100KVA PF1.0 from Upsystem Power manufacturer and contact us to get a quotation.


2. Product feature of 3PHASE ONLINE UPS 100KVA PF1.0


2.1 Wide input voltage range and frequency range

Designed for harsh electrical environments to save battery life, and suitable for fuel generators or other power generation equipment.


2.2 ECO mode

Operating mode that ensures ultra-high efficiency while charging the batteries, conditioning the load power factor, and ensuring a Class 1 output voltage regulation.


2.3 Most advanced and high frequency DSP technology

The high-performance DSP provides UPS more accurate measurements of output voltage and currents, also Fast response to overload and over-voltage conditions.


2.4 Super overload capacity

Long-time working under the load of less than 110%; switching to the bypass in 10min under the load of 111% to 125%; switching to the bypass output in 1min under the load of 126% to 150%,switching to the bypass output in 400ms under the load of more than 150%.


2.5 Generator compatible

Ensures clean, uninterrupted power to protected equipment when generator power is used.


2.6 Cold start and mains start without battery

In the abnormal state of the utility power, the UPS can be started directly with the battery to meet emergency needs.

When there is no battery, the UPS can be started directly from the mains and can be used as a high-precision regulated power supply.


2.7 Protection

Various protections such as surge protection and short-circuit protection are available to ensure the reliability of UPS. It is equipped with battery overvoltage, overcharge, and other protection functions to protect the battery from damage.


2.8 Multi-communication Interface

It offers RS232, USB, RS485, CAN, NET, input and output dry contacts, SNMP board, WIFI board, GPRS board and 4G board to monitor the operating status of UPS.


3. Product Applications of 3PHASE ONLINE UPS 100KVA PF1.0


3PHASE ONLINE UPS 100KVA PF1.0 is suitable for power protection devices such as Security, Monitoring, Alarm.

China Upsystem Power factory has been one of the leading suppliers of 3PHASE ONLINE UPS 100KVA PF1.0 in China. We also provide other products: Low Frequency Online UPS(transformer based online ups), Modular UPS and Solar inverter and other power products.

Our products have been exporting to all over the world, welcome to inquiry 3PHASE ONLINE UPS 100KVA PF1.0.


4. FAQ


1) If OEM is acceptable?

Yes, we can provide the OEM service for Logo printing on UPS, Custom manual etc.


2) How to proceed with an order?

A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.


3) Can I delivery the goods from other supplier to your factory?

Then load together? Sure, that's no problem.


4) Are you a trading company or a manufacturer?

A professional manufacturer and developer of UPS.


5) How is your after-sale service?

We provide 12-24 months warranty period since the delivery date and free maintenance/replacement during warranty period.


6) Do you have any MOQ?

Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.


7) Can I have a sample order?

Yes, we welcome sample order to test and check quality.


8) What kind of material of transformer?

We have two types, one 100% copper and the other is copper with aluminum. It depends on your requirement. In fact, those two have no difference if normal work well. Only except the lifetime. Copper is better and also higher price.
